WES 125 without support

Turnstile for dowelling or setting in concrete
  • Horizontally rotating, all 90° lockable
  • All steel components hot-dip galvanized
  • Rotating support made of steel tube 121.0 x 4.0 mm
  • Main support made of steel tube 101.6 x 2.9 mm
  • One-piece aluminum barrier beam 86 x 46 mm, with anti-seat protection and sign / advertising baffle
  • From 2500 mm with cable reinforcement
  • Without support (only as accessories)
  • Mounting by screwing on the floor plates 250 x 250 mm or setting the mounting cage in concrete
  • Height above ground 1000 mm
  • Various locking options on the main support, in standard for padlock
Downloads Product info (131 KB) Foundation plan (dowel-on) (68 KB) Foundation plan (set in concrete) (73 KB) Mounting instructions (336 KB)
{f:if(condition: '', then: '', else: '{f:if(condition:\'\', then:\'\', else: \'Horizontal rotary barriers WES 125 without support\')}')}
Dowel-on
{f:if(condition: '', then: '', else: '{f:if(condition:\'\', then:\'\', else: \'Horizontal rotary barriers WES 125 without support\')}')}
Set in concrete
{f:if(condition: '', then: '', else: '{f:if(condition:\'\', then:\'\', else: \'Horizontal rotary barriers WES 125 without support\')}')}
{f:if(condition: '', then: '', else: '{f:if(condition:\'\', then:\'\', else: \'Horizontal rotary barriers WES 125 without support\')}')}
{f:if(condition: '', then: '', else: '{f:if(condition:\'\', then:\'\', else: \'Horizontal rotary barriers WES 125 without support\')}')}
{f:if(condition: '', then: '', else: '{f:if(condition:\'\', then:\'\', else: \'Horizontal rotary barriers WES 125 without support\')}')}
{f:if(condition: '', then: '', else: '{f:if(condition:\'\', then:\'\', else: \'Horizontal rotary barriers WES 125 without support\')}')}
{f:if(condition: '', then: '', else: '{f:if(condition:\'\', then:\'\', else: \'Horizontal rotary barriers WES 125 without support\')}')}

Dimensions & Order No.

Length Article no. (dowelled on) Article no. (set in concrete)
1,5 m 3-125-1500-0003 3-125-1500-0027
2,0 m 3-125-2000-0006 3-125-2000-0023
2,5 m 3-125-2500-0002 3-125-2500-0013
3,0 m 3-125-3000-0005 3-125-3000-0025
3,5 m 3-125-3500-0005 3-125-3500-0019
4,0 m 3-125-4000-0007 3-125-4000-0017
4,5 m 3-125-4500-0002 3-125-4500-0018
5,0 m 3-125-5000-0010 3-125-5000-0026
5,5 m 3-125-5500-0008 3-125-5500-0014

Accessories

  • Lock case profile cylinder for: turnstiles and height limitation and WES 31 and WES 41
  • Lock case profile cylinder and fire brigade triangle for: turnstiles and height limitation and WES 31 and WES 41
  • Extension set forced closing for turnstile and height limitation (only in combination with lock case)
  • Support for lock case Fire brigade triangle for vertical turnstiles
  • Lock case support profile cylinder lock for vertical swing locks
  • Extension set triangular lock Simplex for turnstile and height limitation
  • Fire brigade triangular key standard
  • Padlock 60 mm
